Flame Retardant Polyester Nonwoven Filter Media

★      FLAME RETARDANT FILTER MEDIA SERIES

The flame-retardant  filter media series features two types of base materials.

The first type consists of 80% wood pulp fiber and 20% synthetic fiber. The second type is 100% polyester fiber non-woven fabric.

Flame Retardant Filter Media

Flame retardant filter media is designed for industrial dust filtration applications where improved resistance to flame and heat is required. It can be used for dust filter cartridges and other industrial filtration systems operating in demanding environments.

The media can be engineered with different substrate materials and treatment options to meet specific filtration, temperature and flame-retardant requirements.

Key Features

- Flame retardant performance

- Suitable for industrial dust filtration

- Designed for demanding operating environments

- Available with different filter media substrates

- Suitable for dust filter cartridges

100% polyester fiber non-woven fabric：

A.  170GSM Weight Point bonding Flame Retardant: PET-FR/170

B.  260GSM Flame Retardant PET: PET-FR/260

C.  Flame Retardant PET with PTFE membrane: PET-F4FR/260

D.  Can be used for high-temperature media: PET-CF4FR/270

Remark:

a. Air Permeability was tested at △P=200Pa.

b. Filtration Precision, this data refers to the minimum grade of particle size that can be effectively blocked before the initial "dustcake" is established. In the practical using processes, we can improve the filtration precision by using correct filtration velocity, and establishing stable initial "dustcake", etc.

c. Filtration Efficiency was tested by using 8-12 micron 325 mesh talcum powder as test dust with the filtration speed ≤ 1.2m/ min and the concentration of dust (4±0.5)g/m3 ; after more than 5 times cleaning process, filter media makes a good effect on the ratio of filter effectively blocking dust and the total quantity of dust. (JB/T 10341-2014)

d. Filtration Precision Level is tested at the beginning of using, by ASHARE52.2 in USA or EN779 in Europe.

★The various functions of the filter media can be combined with each other, please contact us with your special needs.

★All technical parameters are for reference only (test data may deviate due to test different conditions and equipment), we reserve the right of making changes without prior notice.

Our 100% polyester non-woven flame-retardant filter media is specialized for industrial applications, excelling in welding fume capture and high-risk scenarios involving flammable substances or spark generation. Made from premium polyester fibers, it meets strict industrial fire safety standards, resisting flame spread to safeguard critical operations.

Its non-woven structure ensures efficient particle filtration, low air resistance, and robust durability—ideal for industrial dust collection, welding workshops, and explosive/flammable environments. It maintains structural stability at high temperatures, capturing sparks and hazardous particles while preventing fire hazards.

Easy to process and engineered for industrial rigor, this filter media delivers reliable, long-lasting performance in demanding conditions where fire safety and contamination control are mission-critical. Trust it for secure, high-efficiency filtration in high-risk industrial settings.
