★      PTFE MEMBRANE filter media by DFC FILTRATION

PTFE membrane filter media for industrial dust filtration, offering high filtration efficiency, low dust penetration and reliable performance for dust filter cartridges.

DFC Filtration supplies PTFE membrane filter media for industrial dust filtration applications. Our PTFE membrane media is designed to provide efficient surface filtration, fine dust capture and reliable dust-release performance for industrial dust filter cartridges.

The PTFE membrane can be laminated onto different filter media substrates to meet different filtration and operating requirements.

Key Features

- High-efficiency fine dust filtration

- PTFE membrane surface for effective surface filtration

- Good dust-release performance

- Suitable for industrial dust filter cartridges

- Available with different substrate materials and configurations

- Designed for demanding industrial dust collection applications

A.  160GSM Weight Point bonding PTFE Laminated Nonwoven: PET-F4/160

B.  One-component 260GSM Polyester Nonwoven: PET-F4/260

C.  130GSM Weight Flat Bonding Spun-bonded Polyester: PET-GF1/13

D.  One-component Hot Melt PTFE Membrane waterproof filter media: PET-F2F4/260

E.   Two-component 260GSM Hot Melt High Precision PTFE Membrane: PET-SHF4/260

F.   Large Air Permeability 240GSM Hot Melt High Precision PTFE Membrane: PET-LF4/240

Remark:

a. Air Permeability was tested at △P=200Pa.

b. Filtration Precision, this data refers to the minimum grade of particle size that can be effectively blocked before the initial "dustcake" is established. In the practical using processes, we can improve the filtration precision by using correct filtration velocity, and establishing stable initial "dustcake", etc.

c. Filtration Efficiency was tested by using 8-12 micron 325 mesh talcum powder as test dust with the filtration speed ≤ 1.2m/ min and the concentration of dust (4±0.5)g/m3 ; after more than 5 times cleaning process, filter media makes a good effect on the ratio of filter effectively blocking dust and the total quantity of dust. (JB/T 10341-2014)

d. Filtration Precision Level is tested at the beginning of using, by ASHARE52.2 in USA or EN779 in Europe.

★The various functions of the filter media can be combined with each other, please contact us with your special needs.

★All technical parameters are for reference only (test data may deviate due to test different conditions and equipment), we reserve the right of making changes without prior notice.
